SMD 1-15W 电源转换器

博大提供1-15W SMD type DC to DC converter, 具小体积, low ripple noise,高效率,高操作温度,內置EMI filter …等特色，取得UL/EN/IEC 60950-1, 60601-1, 62368-1, EN50155等相关安规认证，满足客戶industrial / medical / Telecom / railway / IPC …power选型应用或客规品订制服务。

ꁆ ꁇ

넳 넲

系列	输出功率	输入电压（VDC）	输出电压（VDC）	隔离电压	工作温度	封装尺寸（mm)	资料下载
SDS01 SDH01	1W	4.5~9 9~18 18~36 36~75	3.3,5,9,12,15,24 ±5,±12,±15	1600VDC 3000VDC	-40~105°C	SIP-8 13.2×9.1×10.2 SMD-8 14.2×9.1×10.2
SDS01W SDH01W	1W	4.5~18 9~36 18~75	3.3,5,9,12,15,24 ±5,±12,±15	1600VDC 3000VDC	-40~105°C	SIP-8 13.2×9.1×10.2 SMD-8 14.2×9.1×10.2
SDS02 SDH02	2W	4.5~9 9~18 18~36 36~75	3.3,5,9,12,15,24 ±5,±12,±15	1600VDC 3000VDC	-40~105°C	SIP-8 13.2×9.1×10.2 SMD-8 14.2×9.1×10.2
SDS0 2W SDH02W	2W	4.5~18 9~36 18~75	3.3,5,9,12,15,24 ±5,±12,±15	1600VDC 3000VDC	-40~105°C	SIP-8 13.2×9.1×10.2 SMD-8 14.2×9.1×10.2
SDS03W SDH03W	3W	4.5~18 9~36 18~75	3.3,5,9,12,15,24 ±5,±12,±15	1600VDC 3000VDC	-40~105°C	SIP-8 13.2×9.1×10.2 SMD-8 14.2×9.1×10.2
SDS05 SDH05	5W	4.5~13.2 9~18 18~36 36~75	3.3,5,9,12,15,24 ±5,±12,±15	1600VDC 3000VDC	-40~105°C	SIP-8 13.2×9.1×10.2 SMD-8 14.2×9.1×10.2
SDS05W SDH05W	5W	9~36 18~75	3.3,5,9,12,15,24 ±5,±12,±15	1600VDC 3000VDC	-40~105°C	SIP-8 13.2×9.1×10.2 SMD-8 14.2×9.1×10.2
UDS01 UDH01	1W	4.5~13.2 9~18 18~36 36~75	3.3,5,9,12,15,24 ±5,±12,±15	1600VDC	-40~105°C	SIP-5 11.9×7.7×11.0 SMD-7 12.1×11.9×8.0
UDS0 2 UDH02	2W	4.5~13.2 9~18 18~36 36~75	3.3,5,9,12,15,24 ±5,±12,±15	1600VDC	-40~105°C	SIP-5 11.9×7.7×11.0 SMD-7 12.1×11.9×8.0
UDS0 3 UDH03	3W	4.5~13.2 9~18 18~36 36~75	3.3,5,9,12,15,24 ±5,±12,±15	1600VDC	-40~105°C	SIP-5 11.9×7.7×11.0 SMD-7 12.1×11.9×8.0
PDS02 PDH02	2W	4.5~9 9~18 18~36 36~75	3.3,5,9,12,15 ±5,±12,±15	1600VDC 3000VDC	-40~100°C	DIP-14 18.9×12.8×8.7 SMD-14 18.9×17.2×8.7
PDS02W PDH02W	2W	4.5~18 9~36 18~75	3.3,5,9,12,15 ±5,±12,±15	1600VDC 3000VDC	-40~100°C	DIP-14 18.9×12.8×8.7 SMD-14 18.9×17.2×8.7
PDS03 PDH03	3W	4.5~9 9~18 18~36 36~75	3.3,5,9,12,15 ±5,±12,±15	1600VDC 3000VDC	-40~100°C	DIP-14 18.9×12.8×8.7 SMD-14 18.9×17.2×8.7
PDS03W PDH03W	3W	4.5~18 9~36 18~75	3.3,5,9,12,15 ±5,±12,±15	1600VDC 3000VDC	-40~100°C	DIP-14 18.9×12.8×8.7 SMD-14 18.9×17.2×8.7
MPS02 MPH02	2W	4.5~12 9~18 18~36 36~75	3.3,5,9,12,15,24 ±5,±12,±15	5000VAC	-40~105°C	DIP-16 24.3×14.4×10.2 SMD-16 24.3×18.1×10.5
MPS04 MPH04	3.5W	4.5~12 9~18 18~36 36~75	5,9,12,15,24 ±5,±12,±15	5000VAC	-40~105°C	DIP-16 24.3×14.4×10.2 SMD-16 24.3×18.1×10.5
FKC03	3W	9~18 18~36 36~75	3.3,5,12,15 ±5,±12,±15	1600VDC	-25~100°C -40~105°C	DIP-24 31.8×20.3×10.2 SMD-24 32.0×25.4×11.2
MKC03	3W	9~18 18~36 36~75	3.3,5,12,15 ±5,±12,±15 5/5,12/12,15/15	500VDC	-25~85°C -40~85°C	DIP-24 31.8×20.3×10.2 SMD-24 32.0×25.4×11.2
PFKC03	3W	4.5~6 9~18 18~36 36~75	3.3,5,12,15 ±5,±12,±15	1600VDC 3000VDC	-25~100°C	DIP-24 31.8×20.3×10.2 SMD-24 32.0×25.4×12.0
PMKC03	3W	4.5~6 9~18 18~36 36~75	3.3,5,12,15 ±5,±12,±15 5/5,12/12,15/15	1600VDC	-25~100°C	DIP-24 31.8×20.3×10.2 SMD-24 32.0×25.4×12.0
FKC05 FKC05W	5W	9~18 18~36 36~75	3.3,5,12,15 ±5,±12,±15	1600VDC	-25~100°C -40~105°C	DIP-24 31.8×20.3×10.2 SMD-24 32.0×25.4×11.2
PFKC05	5W	9~18 18~36 36~75	3.3,5,12,15 ±5,±12,±15	1600VDC 3000VDC	-25~100°C	DIP-24 31.8×20.3×10.2 SMD-24 32.0×25.4×12.0
FKC08	8W	9~18 18~36 36~75	3.3,5,12,15 ±5,±12,±15	1600VDC	-40~100°C -55~100°C	DIP-24 31.8×20.3×10.2 SMD-24 32.0×25.4×11.2
FKC08W	8W	9~36 18~75 43~160	3.3,5,12,15 ±5,±12,±15	1600VDC	-40~105°C -55~105°C	DIP-24 31.8×20.3×10.2 SMD-24 32.0×25.4×11.2
FKC12	12W	9~18 18~36 36~75	2.5,3.3,5.1,12,15 ±5,±12,±15	1600VDC	-40~100°C	DIP-24 31.8×20.3×10.2 SMD-24 32.0×25.4×11.2
FKC12W	12W	9~36 18~75	2.5,3.3,5.1,12,15 ±5,±12,±15	1600VDC	-40~105°C	DIP-24 31.8×20.3×10.2 SMD-24 32.0×25.4×11.2
LED15	15W	18~36 36~75	12.15	2250VDC	-40~105°C	DIP-24 27.9×23.9×8.5 SMD-24 27.9×23.9×9.0
LED15W	15W	9~36 18~75	3.3,5,12,15	2250VDC	-40~105°C	DIP-24 27.9×23.9×8.5 SMD-24 27.9×23.9×9.0
